SMC - Grippers

มีทั้งหมด 4 รุ่น คือ

Easy setting: Data can be set with only 2 items, position and force. The controller is already set with the data of the actuator. (The actuator and controller are provided as a set.)
Equipped with a drop prevention function (All series come equipped with a self-lock mechanism.)
The self-lock mechanism reduces power consumption.
Equipped with a gripping check function
It is possible to set the position, speed, and force. (64 points)

Model	Body size	Stroke/ both sides (mm)	Gripping force [N] Basic	Gripping force [N] Compact	Opening and closing speed (mm/s)
LEHZ	10	4	6 to 14	2 to 6	5 to 80
LEHZ	16	6	6 to 14	3 to 8	5 to 80
LEHZ	20	10	16 to 40	11 to 28	5 to 100
LEHZ	25	14	16 to 40	11 to 28	5 to 100
LEHZ	32	22	52 to 130	-	5 to 120
LEHZ	40	30	84 to 210	-	5 to 120

Easy setting: Data can be set with only 2 items, position and force. The controller is already set with the data of the actuator. (The actuator and controller are provided as a set.)
Equipped with a drop prevention function (All series come equipped with a self-lock mechanism.)
The self-lock mechanism reduces power consumption.
Equipped with a gripping check function
It is possible to set the position, speed, and force. (64 points)

Model	Body size	Stroke/ both sides (mm)	Gripping force [N] Basic	Gripping force [N] Compact	Opening and closing speed (mm/s)
LEHZJ	10	4	6 to 14	3 to 6	5 to 80
LEHZJ	16	6	6 to 14	4 to 8	5 to 80
LEHZJ	20	10	16 to 40	11 to 28	5 to 100
LEHZJ	25	14	16 to 40	11 to 28	5 to 100

Easy setting: Data can be set with only 2 items, position and force. The controller is already set with the data of the actuator. (The actuator and controller are provided as a set.)
Equipped with a drop prevention function (All series come equipped with a self-lock mechanism.)
The self-lock mechanism reduces power consumption.
Equipped with a gripping check function
It is possible to set the position, speed, and force. (64 points)
Note ( ): For long strokes

Model	Body size	Stroke/ both sides (mm)	Gripping force [N] Basic	Gripping force [N] Compact	Opening and closing speed (mm/s)
LEHF	10	16 (32) Note)	3 to 7	3 to 7	5 to 80
LEHF	20	24 (48) Note)	11 to 28	11 to 28	5 to 100
LEHF	32	32 (64) Note)	48 to 120	48 to 120	5 to 100
LEHF	40	40 (80) Note)	72 to 180	72 to 180	5 to 100

Easy setting: Data can be set with only 2 items, position and force. The controller is already set with the data of the actuator. (The actuator and controller are provided as a set.)
Equipped with a drop prevention function (All series come equipped with a self-lock mechanism.)
The self-lock mechanism reduces power consumption.
Equipped with a gripping check function
It is possible to set the position, speed, and force. (64 points)
